Product Details:
|
| Model: | TT230 | Type: | Industrial Grade Instrument |
|---|---|---|---|
| Material: | Aeronautical Metal Shell | Probe Type: | N1 Non-magnetic Probe |
| Dimension(L*W*H): | 150*55.5*23MM | Weight: | 150g |
| Measuring Principle: | Electric Eddy Current | Measuring Range: | 0-1250μm（Chromium Plating On Copper0-40μm） |
| Floor Resolution: | 0.1μm | Power: | Lithium Battery |
| Working Environment: | 0-40℃,20%RH-90%RH | Attachment: | Mainframe, Standard Chip, File, Iron Matrix, Charger |
| Highlight: | Non Magnetic TT230 Paint Thickness Gauge,TT230 Paint Thickness Gauge,N1 paint thickness checking machine |
||
TT230 Non-Magnetic All-In-One Machine Industrial Coating Thickness Gauge
Introduction
The eddy current thickness measurement method is adopted in this instrument, which can measure the thickness of non-conductive coating on non-magnetic metal substrate (such as enamel, rubber, paint coating on copper, aluminum, zinc, tin, etc.) without damage.Zero point calibration and two point calibration can be carried out, and the system error of the probe can be corrected by the basic calibration method.There are two kinds of measurement methods: continuous measurement mode (CONTINUE) and single measurement mode (SINGLE).(Appl) has two working modes: direct mode (DIRECT) and group mode (Appl).Delete function: delete a single suspicious data that appears in the measurement, or delete all data in the storage area for new measurements.There are five statistics: average (MEAN), maximum (MAX), minimum (MIN), test times (NO.), standard deviation (S.DEV).It has the function of conversion from meter to imperial system.The utility model has the function of printing, and can print measured values and statistical values.It has the function of undervoltage indication.There is a beep during the operation."has the function of error prompt.The machine has the function of automatic shutdown.Non-magnetic probe can only measure the coating on the surface of aluminum-based (non-magnetic metal) (can only be non-metal).
Application
One machine is widely used in metal processing, automobile evaluation, chemical industry, ship manufacturing, galvanizing measurement and other testing fields. It is an indispensable instrument for material protection.
Quick Details
| Dimension(L*W*H) | 150*55.5*23MM | Model | TT230 |
| Type | Industrial grade instrument | Measuring principle | Electric eddy current |
| Power | Lithium battery | Floor resolution | 0.1μm |
| Magnetic measuring range | 0-1250μm(Chromium plating on copper0-40μm) | Working environment | 0-40℃,20%RH-90%RH |
| Weight | 150g | Probe type | N1 Non-magnetic probe |
Advantages and selling points
1. Light and easy to carry, work anytime and anywhere.
2. Easy to operate and easy to learn.
3. The anticorrosion of the instrument is strong and durable.
4. Industrial grade and accurate measurement.
5. The price is good and the after-sale is good.
Package
Paper box package
