Product Details:
|
Material: | PVC Plastic Shell Material | Model: | TT360 |
---|---|---|---|
Measuring Precision: | 0.01mm Or 0.001mm | Type: | Coating Penetration Intelligent Type |
Display: | LED Liquid Crystal Display | Weight: | 220g |
Material Temperature: | 0°C - 500°C(It Depends On The Probe) | Measuring Range: | 0.6-400mm(Double Crystal Probe) |
Power: | 2* AA Battery(1.5V) | Dimension(L*W*H): | 150*70*35mm |
Measuring Frequency: | 5MHz | Sound Velocity Range: | 1000-9999m/s |
Highlight: | TT360 ultrasonic gauge thickness tester,LED through coating ultrasonic thickness gauge,through coating ultrasonic thickness gauge |
TT360 Precision Coating Penetration Type Ultrasonic Coating Thickness Gauge
Introduction
TT360 ultrasonic coating thickness Gauge is a portable ultrasonic thickness gauge.It adopts the measurement method of double crystal probe multiple echoes to "penetrate the coating", which does not need to remove the coating at the measuring point, and saves time and cost for users.
Application
It is applied to glass thickness measurement, steel wall thickness measurement, element thickness measurement, plastic thickness measurement and so on.
Quick Details
Material | PVC plastic shell material | Model | TT360 |
Type | Coating Penetration Intelligent type | Material temperature | 0°C - 500°C |
Power | 2*AA battery | Measuring precision | 0.01mm or 0.001mm |
Measuring range | 0.6-400MM | Display | LED liquid crystal display |
Weight | 220g | Dimension(L*W*H) | 150*70*35mm |
Advantages and selling points
1. Penetrate the coating to save time and cost.
2. Industrial grade special instrument.
3. Easy to carry.
4. The measured value does not jump.
Package
Paper box package
