GM03 –Spare parts list
|
||
|
GM03 manual powder gun –complete
|
||
|
A
|
negative polarity, incl. gun cable –6 m, rinsing air hose –6 m, flat jet nozzle, brush and parts kit, without powder hose
|
1008 070
|
|
|
GM03 manual powder gun –complete
|
1008 073
|
|
positive polarity, incl. gun cable –6 m, rinsing air hose –6 m, flat jet nozzle, brush and parts kit, without powder hose
|
||
|
B
|
Manual powder gun shaft OptiSelect GM03 (incl. cascade) with:
|
|
|
|
Gun cable 2 m, negative polarity (–)
|
1007 971
|
|
|
Gun cable 6 m, negative polarity (–)
|
1007 972
|
|
|
Gun cable 12 m, negative polarity (–)
|
1007 973
|
|
|
Gun cable 2 m, positive polarity (+)
|
1007 974
|
|
|
Gun cable 6 m, positive polarity (+)
|
1007 975
|
|
|
Gun cable 12 m, positive polarity (+)
|
1007 968
|
|
1
|
Gun body
|
1007 220
|
|
2
|
Cascade –complete, negative polarity
|
1007 231
|
|
|
Cascade –complete, positive polarity
|
1007 232
|
|
3
|
Print holder –complete
|
1007 216
|
|
4
|
End plate with hook
|
1007 217
|
|
5
|
Grip –complete (incl. pos. 5.1 and 5.2)
|
1007 961
|
|
5.1
|
Grub screw –M3x8 mm
|
1008 157
|
|
5.2
|
Grip sealing
|
1007 633
|
|
6
|
Trigger –complete
|
1007 213
|
|
7
|
Trigger cover
|
1007 212
|
|
8
|
Countersunk-head screw –M4x6 mm
|
1000 845
|
|
9
|
SuperCorona connection
|
1007 238
|
|
10
|
Gun cable 2 m –complete
|
1007 963
|
|
|
Gun cable 6 m –complete
|
1007 964
|
|
|
Gun cable 12 m –complete
|
1007 965
|
|
11
|
Rinsing air connection
|
1000 804
|
|
11.1
|
Rinsing air hose
|
100 854*
|
|
12
|
Powder tube –complete
|
1007 958 #
|
|
13
|
Compression spring
|
1001 488
|
|
14
|
Clip ring
|
1007 960
|
|
15
|
Hose connection Ø 11-12 mm –complete (incl. pos 15.1)
|
1001 340 #
|
|
|
Hose connection Ø 9-10 mm –complete (incl. pos 15.1)
|
1002 030 #
|
|
15.1
|
O-ring for pos. 15
|
1000 822 #
|
|
16
|
Threaded sleeve (see corresponding spare parts list)
|
|
|
18
|
Cascade space gasket
|
1007 635#
|
|
|
Cleaning brush –Ø 12 mm
|
389 765
|
|
|
Parts set (not shown), consisting of:
|
1008302
|
|
|
Flat jet nozzle NF21
|
1007 935#
|
|
|
Adapter NF08
|
1003634#
|
|
|
Cable clamp
|
303 070
|
|
|
Hose connector –complete, for hose interior Ø 9-10mm
|
1002030
|
|
1
|
Corona PC05
|
1008 165#
|
|
|
NF20 Profiles/flat parts (standard nozzle)
|
1010 090
|
|
|
NF27 Profiles/flat parts
|
1010 752
|
|
|
NF21 Complex profiles and depressions
|
1007 935
|
|
|
NF22 Complex parts (deep recess), target spraying
|
1008 145
|
|
|
NF24 Large surfaces
|
1008 147
|
|
|
electrode
|
1007 683
|
|
|
NF20 flat nozzle complete
|
1010 160
|
|
|
NF27 flat nozzle complete
|
1010 754
|
|
|
NF21 flat nozzle complete
|
1007 932
|
|
|
NF22 flat nozzle complete
|
1008 140
|
|
|
NF24 Large surfaces
|
1008 142
|
|
|
Threaded sleeve
|
1008 326
|
|
|
Threaded sleeve
|
1007 229
|
|
|
NS04 Round jet nozzle
|
1008 151
|
|
|
round electrode
|
1008 152
|
|
|
Round jet nozzle complete
|
1008 150
|
|
|
Threaded sleeve
|
1007 229
|
|
|
Deflectors Ø 16mm
|
331 341
|
|
|
Deflectors Ø 24 mm
|
331 333
|
|
|
Deflectors Ø 32 mm
|
331 325
|
|
|
Deflectors Ø 50 mm
|
345 822
|
|
|
Gun extensions without nozzle L = 150 mm
|
1008 616
|
|
|
Gun extensions without nozzle L = 150 mm
|
1007 718
|
|
|
Gun extensions with Flat jet nozzle NF25 L = 150 mm
|
1007 746
|
|
|
Gun extensions with Round jet nozzle NS09 L = 150 mm
|
1007 748
|
|
|
Gun extensions without nozzle L = 300 mm
|
1008 617
|
|
|
Gun extensions without nozzle L = 300 mm
|
1007 719
|
|
|
Gun extensions with Flat jet nozzle NF25 L = 300 mm
|
1007 747
|
|
|
Gun extensions with Round jet nozzle NS09 L = 300 mm
|
1007 749
|
|
|
NF25 Profiles/flat parts
|
1007 735
|
|
|
NF26 Complex profiles and depressions
|
1007 742
|
|
|
NS09 Suitable for large surfaces
|
1008 257
|
|
|
Electrode
|
1007 684
|
|
|
Electrode
|
1008 258
|
|
|
NF25 flat nozzle complete
|
1007 743
|
|
|
NF26 flat nozzle complete
|
1007 744
|
|
|
NS09 round nozzle complete
|
1008 259
|
|
|
Threaded sleeve
|
1007 740
|
|
|
POE Antistatic powder hoses Ø 11/16 mm
|
105 139
|
|
|
POE Antistatic powder hoses Ø 12/18 mm
|
1001 674
|
|
|
POE Antistatic powder hoses Ø 10/15 mm
|
1001 673
|
|
|
Powder cup 500 ml
|
1002 069
|
