Item
|
Part
|
Description
|
Quantity
|
Note
|
|
−
|
1106893
|
HANDGUN assembly, Encore LT
|
1
|
|
|
1
|
1081638
|
•NUT, nozzle, handgun
|
1
|
|
|
2
|
1081658
|
•NOZZLE, fat spray, 4 mm
|
1
|
A
|
|
3
|
1604824
|
•ELECTRODE ASSEMBLY, Encore, fat spray
|
1
|
F
|
|
3A
|
1106078
|
• •ELECTRODE, spring contact
|
1
|
|
|
3B
|
1605863
|
• •HOLDER, electrode, M3, fat spray, Encore
|
1
|
F
|
|
4
|
1085024
|
•KIT, powder outlet tube, Encore
|
1
|
D
|
|
4A
|
941113
|
• •O-RING, silicone, 0.438 x 0.625 x 0.094 in.
|
1
|
|
|
5
|
1081785
|
• •O-RING, silicone, 0.468 x 0.568 x 0.05 in.
|
1
|
|
|
6
|
1088502
|
•GASKET, multiplier cover, handgun
|
1
|
|
|
7
|
1106872
|
•BULKHEAD, multiplier, handgun, Encore LT/XT
|
1
|
|
|
8
|
1087559
|
•COVER, housing, Encore
|
1
|
|
|
9
|
1618782
|
•KIT, gun display housing
|
1
|
|
|
10
|
1087760
|
•HOOK, handgun
|
1
|
|
|
11
|
1078075
|
•SCREW, pan head, recessed, M3 x 30, zinc
|
1
|
|
|
12
|
760580
|
•SCREW, Philips head, M3 x 20, zinc
|
3
|
|
|
13
|
1608280
|
•KIT, negative power supply/manual body, Encore
|
1
|
G
|
|
14
|
1088558
|
• •FILTER ASSEMBLY, handgun
|
1
|
|
|
15
|
1106871
|
•HANDLE, ground pad, handgun, Encore LT/XT
|
1
|
|
|
16
|
983520
|
•WASHER, lock, internal, M3, zinc
|
1
|
|
|
17
|
982427
|
•MACHINE SCREW, pan head, recessed, M3 x 6, zinc
|
1
|
|
|
18
|
1096695
|
•ELBOW, powder tube, handgun
|
1
|
D
|
|
19
|
1081540
|
•TRIGGER, purge, setting, handgun
|
1
|
|
|
20
|
1606999
|
•KIT, trigger w axle, Encore
|
1
|
|
|
20A
|
− − − − −
|
• •AXLE, trigger, solid, spray gun, Encore
|
1
|
|
|
21
|
1106892
|
• •ACTUATOR, switch, trigger, Encore LT/XT
|
1
|
|
|
22
|
1088601
|
•SCREW, fat head, recess, M5x 10, nylon
|
1
|
|
|
23
|
1108095
|
•KIT, trigger switch, Encore LT
|
1
|
|
|
24
|
1106870
|
•HANDLE, handgun, Encore LT/PE
|
1
|
|
|
25
|
1085026
|
•KIT, powder inlet tube, Encore
|
1
|
|
|
25A
|
1084773
|
• •O-RING, silicone, 18 mm ID x 2 mm wide
|
2
|
|
|
25B
|
1081785
|
• •O-RING, silicone, 0.468 x 0.568 x 0.05 in.
|
1
|
|
|
26
|
1106756
|
•CABLE ASSEMBLY, spray gun, manual, Encore LT, 6 meter
|
1
|
E
|
|
26A
|
940129
|
• •O-RING, silicone, conductive, 0.375 x 0.50in.
|
1
|
|
|
26B
|
1604500
|
• •CLAMP, cable, 0.25 ID x 0.05 thick, white
|
1
|
|
|
27
|
1087762
|
•BASE, handle, handgun
|
1
|
|
|
28
|
1081617
|
•CHECK VALVE, male, M5 x 6 mm
|
1
|
|
|
29
|
1081616
|
•FITTING, bulkhead, barb, dual, 10−32 x 4 mm
|
1
|
|
|
30
|
1081777
|
•RETAINING RING, external, 10 mm
|
1
|
|
|
31
|
1604828
|
•KIT, conical nozzle, Encore
|
|
|
|
32
|
1083206
|
• •DEFLECTOR ASSEMBLY, conical, 26 mm
|
1
|
A
|
|
Continued...
|
